ECLER DROP6 is a 2-way 6.5”, 75W@8ohm pendant loudspeaker with a stylish design, including a 70/100V line transformer with 60/30/15 and 7,5W power sel
ECLER DROP6 is a 2-way 6.5”, 75W@8ohm pendant loudspeaker with a stylish design, including a 70/100V line transformer with 60/30/15 and 7,5W power selections, available at both high and low impedance levels. Dimensions (without accessories) Ø270mm x 355mm(H) / Ø10.6 in. x 14 in. (H). Weight 4.2 Kg / 9.26 lb. Stripped wire connection (5m). Colour white.
ECLER DROP6 is a 2-way 6.5”, 75W@8ohm pendant loudspeaker with a stylish design, including a 70/100V line transformer with 60/30/15 and 7,5W power sel
ECLER DROP6 is a 2-way 6.5”, 75W@8ohm pendant loudspeaker with a stylish design, including a 70/100V line transformer with 60/30/15 and 7,5W power selections, available at both high and low impedance levels. Dimensions (without accessories) Ø270mm x 355mm(H) / Ø10.6 in. x 14 in. (H). Weight 4.2 Kg / 9.26 lb. Stripped wire connection (5m). Black colour.
Episode® 650 Commercial Series 70V Pendant Speaker with 4 in. Woofer and Gripple™ Kit (Black | Each)
Specifications
UL1480 Listed: Yes
Woofer: 4″ Vacuum-formed, Mica-Filled Polypropylene
Woofer Voice Coil: 1.2″ Copper on Aluminum Bobbin
Tweeter: 1″ Silk Dome with Ferro-fluid cooled Neodymium Magnet
Power Handling RMS (w) @Low Impedance: 40w
Power Handling Peak (w) @Low Impedance: 80w
70v Operation (Yes/No): Yes
70v Tap Settings: 3.75w, 7.5w, 15w, 30w
100v Tap Settings: 7.5w, 15w, 30w
Low Impedance Bypass: Yes
Recommended Amplifier Power @Low Impedance: 15W
Nominal Impedance – Bypass Mode (O): 😯
Frequency Response (- 3dB): 65Hz – 20kHz
Sensitivity (2.83v @ 1m): 84 db
Dispersion Angle: 130°
Product Weight: 6.0 lbs
Product Dimensions (Diam x H): 8.9″ x 9.1″
Suspension System: Gripple® Hardware Kit with 10-ft Cable
Warranty: Lifetime
spherical pendant loudspeaker featuring a 6,5″ woofer, 0.5″ tweeter and 70/100V transformer
eUC106 is a spherical pendant loudspeaker featuring a 6.5” woofer, 1” tweeter and 70/100V transformer.
Spherical pendant type loudspeaker
8 O and 70/100 V (40W RMS)
6.5” woofer + 1” tweeter
Transformer selector: 32W-16W-8W-4W 100V / 16W-8W-4W-2W 70V – 😯
Stripped wire connection (3m)
Available in white (RAL9003) and black (RAL9005) finish
Effective Freq. Range
74 Hz-20 kHz (-10dB)
Power handling
40 W RMS / 160 W Peak
Maximum SPL
106 dB continuous / 112 dB peak
Power options
70V: 16W / 8W / 4W / 2W / 8 Ohm
Included accessories
Mounting accessories
Cable length
3m
spherical pendant loudspeaker featuring a 6,5″ woofer, 0.5″ tweeter and 70/100V transformer
eUC106 is a spherical pendant loudspeaker featuring a 6.5” woofer, 1” tweeter and 70/100V transformer.
Spherical pendant type loudspeaker
8 O and 70/100 V (40W RMS)
6.5” woofer + 1” tweeter
Transformer selector: 32W-16W-8W-4W 100V / 16W-8W-4W-2W 70V – 😯
Stripped wire connection (3m)
Available in white (RAL9003) and black (RAL9005) finish
Effective Freq. Range
74 Hz-20 kHz (-10dB)
Power handling
40 W RMS / 160 W Peak
Maximum SPL
106 dB continuous / 112 dB peak
Power options
70V: 16W / 8W / 4W / 2W / 8 Ohm
Included accessories
Mounting accessories
Cable length
3m
